2P 1500VDC T2 Surge Protective Device with 40kA Maximum Discharge Current (1).jpg
2P 1500VDC T2 Surge Protective Device with 40kA Maximum Discharge Current (2).jpg

2P 500VDC T2 Surge Protective Device with 40kA Discharge Capacity

This 2P 500VDC T2 Surge Protective Device is designed to provide reliable protection for medium voltage DC systems against transient overvoltages and lightning strikes. The device utilizes a durable plastic housing that offers excellent electrical insulation and mechanical stability. With a maximum discharge capacity of 40kA and nominal discharge current of 20kA, this SPD ensures consistent performance for electrical equipment operating in 500VDC applications. The product incorporates modern protection technology to maintain system integrity and prevent equipment damage under various operational conditions.

    Contact us
    product details

    Key Features and Advantages

    • Medium voltage DC protection specifically designed for 500VDC systems
    • 40kA maximum discharge current capacity for effective surge protection
    • Rapid response time under 25 nanoseconds ensures optimal performance
    • Thermal protection mechanism with automatic disconnection feature
    • Visual status indication for operational monitoring
    • Standard DIN rail mounting for installation convenience
    • Wide operating temperature range from - 45°C to +85°C
    • Compliance with IEC 6164311 international standards
    • Durable construction suitable for industrial environments

    Application Scenarios

    The device is engineered for deployment in various applications including:
     Industrial power distribution systems
     Renewable energy generation facilities
     Power transmission infrastructure
     Transportation systems
     Telecommunications equipment
     Medium voltage DC power networks
     Equipment protection in industrial plants
     Lightning protection systems

    Technical Specifications

    Maximum Discharge Current: 40kA (8/20μs)
     Nominal Discharge Current: 20kA (8/20μs)
     Rated Voltage: 500VDC
     Protection Level: ≤4.0kV
     Protection Level: T2
     Number of Poles: 2P
     Housing Material: Plastic (UL94 V0)
     Response Time: <25 ns
     Operating Temperature Range: - 45°C to +85°C
     Protection Mode: L+/L/PE
     Connection Type: Screw terminal
     Mounting: 35mm DIN rail
     Protection Rating: IP20
     Standards Compliance: IEC 6164311

    This surge protective device offers reliable performance and comprehensive protection for medium voltage DC systems. Its technical features and robust construction ensure equipment safety and system reliability across various industrial applications. The device meets international standards for surge protective devices and provides effective protection against electrical surges and transient overvoltages in demanding operational environments.
